Toshiba D9MM-11A,
9 IN Monochrome CRT MONITOR REPLACEMENT

Model QES1508-057 8.4 In LCD replaces Toshiba D9MM-11A ,  9 In, TTL CRT Monitors used in Fanuc 0-C, 0-TC, 0-MC Series Control Panels.

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.


Toshiba D9MM-11A, 9 IN Monochrome CRT MONITOR REPLACEMENT LCD

When the A61L-0001-0093 or Toshiba D9MM-11A  9 inch Monochrome CRT display in your Fanuc 0-C, 0-TC, 0-MC Series CNC Machine control fails and you need to find a drop-in replacement monitor quickly, look no further. Our QES1508-057 is a high performance, 8.4 inch Active Matrix TFT LCD monitor whose rugged, open frame steel chassis is designed to drop right into the mounting holes of the original Fanuc 9 In CRT, making it unnecessary to replace or make expensive modifications to the original FANUC CRT monitor chassis.

The QES1508-057 operates of 24 volts DC and accepts the Monochrome and Red-Green-Blue (RGB) TTL video signals used in Fanuc 0-C, 0-TC, 0-MC Series CNC Machine control for the original A61L-0001-0093 9 inch FANUC monitor with no need for signal adapters of any sort. This unit has been optimized to operate at the Fanuc 0-C, 0-TC, 0-MC monitor timing but also operates with a variety of other TTL legacy monitor timing as well.

Featuring 600:1 contrast ratios and 450 nits brightness, the rugged QES1508-057 RGB-TTL LCD TFT display is an excellent replacement monitor for your legacy FANUC CRT display.

GE FANUC A61L-0001-0093 or Toshiba D9MM-11A, 9 IN Color Display Replacement LCD On Customer Provided Chassis.

GE FANUC A61L-0001-0093 or Toshiba D9MM-11A, 9 IN CRT Display Replacement LCD On Customer Provided Chassis.

Equivalent Models: A61L-0001-0093, A61L00010093, D9MM-11A, D9MM11A

QES1508-057 Series Features

  • Toshiba D9MM-11A 9 Inch CRT monitor Replacement
  • Fanuc A61L-0001-0093 9 Inch CRT monitor Replacement
  • Honda MR-20M - Fanuc Input Connector
  • RGB TTL video Input meets Fanuc Series Fanuc 0-C, 0-TC, 0-MC control timing standards
  • Power Requirements: 24 VDC (19-35V) @ 1.6 Amp max

Other Options Include

  • Anti-Reflective Protective Faceplate
  • Strengthened Glass Protection
  • Wireless Remote Control
  • Green or White Color
