19″ MRD1819GS-TP Table Top Monochrome Series, Rugged COTS LCD Display

The rugged MRD1819GS-TP 19-inch tabletop Flat Panel LCD monochrome Monitor is a high quality, Mil-Spec Compliant, FLIR-compatible Display for use in Military applications that need an LCD desktop monitor capable of accepting RS-170 and RS-343 video formats in high-noise environments.

The MRD1819GS-TP Series is a 19 In Monochrome Military Grade COTS Display designed to operate in rugged environments and also develop with high performance, reliability, and durability in mind.  The rugged mechanical and electrical design makes this monitor ideal for operating where a Military Rugged Display is required.



At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.


Dynamic Displays' rugged MRD1819GS-TP 19-inch tabletop Flat Panel LCD Monitor is a Mil-Spec Compliant Display designed for use in various Military applications that require a high-quality monochrome FLIR-compatible LCD desktop monitor capable of accepting RS-170 and RS-343 video formats in a high-noise environment. If you are looking for a large desktop COTS Military Monitor that can display FLIR - Forward Looking Infrared Imaging Systems, the MRD1819G 19-inch tabletop Military Display is an excellent choice for you. The MRD1819GS-TP Series 19 In Monochrome Military Grade COTS Display is designed to operate in rugged environments. It was developed from the ground up with high performance, reliability, and durability in mind. The rugged mechanical and electrical design makes this monitor ideal for operating where a Military Rugged Display is required. Features include High Contrast Ratio (1000:1), High Brightness Level (1300 Nits), Wide Operating Temperature Range, Bonded Anti-Reflective Protective Faceplate Glass for Superior Optical Performance and Better Protection on Extreme Environments, STANAG 3350 Video and Monochrome RS-170 Video compatible. These monitor features make the MRD1819GS-TP COTS Military LCD display ideal for applications such as; Air Traffic Control, Airborne, Aviation Display, Ground Mobile, Military Navigation Display Monitor, Ship Board (Submarine and Surface Warship), Shipboard Automation, Stationary Air Defense Systems. If you need COTS Military Display, Ground Control Station – GCS, Rugged COTS Monochrome Monitor, or just have a general-purpose need for a rugged computer monitor, the MRD1819GS-TP series of COTS LCD Monitors is an excellent solution for your rugged display requirements.
19 In Monochrome Military Grade COTS Display

19 In Monochrome Military Grade COTS Display Input Connectors

MRD1819GS-TP Series Features

  • 19 In Monochrome Active Matrix High Bright TFT LCD with Solid State LED Backlight
  • 1280 x 1024 Native Resolution
  • High Bright TFT Display - 1500 Nits
  • High Contrast - 1000:1 Typical
  • Full-Range Dimming to Black
  • Monochrome RS-170 or STANAG 3350 Video signal Compatible
  • NTSC/PAL (RCA Jack) and S-Video (4 Pin Mini-Din)
  • DVI-I and VGA Inputs
  • Convenient Front Controls
  • Aspect Ratio: 1:1 or 4:3 (OSD Selection)
  • Picture In Picture (PIP) and Picture-Outside-Picture (POP) Capable
  • Image Size & Position Adjustment
  • 90-264 VAC or 12VDC Power
  • Bonded Anti-Reflective Protective Faceplate Glass for Superior Optical Performance and Better Protection in Extreme Environments
  • Heavy Duty Aluminum Front Bezel, Heavy Duty Cold Roll Steel Chassis
  • VESA 100 Standard Mounting
  • Conformal Coating of Internal Assemblies to Enhance Ruggedization
  • Front Manual Full Range Brightness and Contrast Control (Dimming)
  • Custom Designs Including Spec, Color, Finish, and Format
  • Designed Engineered and Built to Comply with Military Standards

Other Options Include

  • 24V, 28 and 48V DC Input Voltage Options
  • 3 Buffered Unity-Gain BNC Outputs (RGB)
  • 91 Ohm Video Termination
  • Differential Video Input for Enhanced Noise Immunity
  • Integrated Heaters for Extended Operational Temperature Capabilities
  • Touch Screen Option (SAW, Resistive and Capacitive)
