Industrial Grade
17″ Tabletop LCD Monitor
Metal Enclosure

17″ Industrial-Grade desktop LCD Monitor accepts a variety of legacy signal formats including older RS-170, RS-343, Composite Video, Sync-on-Green (SOG) signals and formats up to SXGA resolutions. For other legacy or replacement applications, this 17 in Tabletop LCD display can be configured for compatibility with TTL CGA / EGA / MDA and virtually any sub VGA signal, analog or digital.

INDUSTRIAL-GRADE TABLETOP 17 In LCD MONITOR WITH METAL ENCLOSURE - Interface Panel

INDUSTRIAL-GRADE TABLETOP 17 In LCD MONITOR WITH METAL ENCLOSURE – Interface Panel

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.


QES1517 Table Top Series - 17” INDUSTRIAL GRADE TABLETOP DISPLAY
Dynamic Displays has developed a 17 in Industrial Desktop LCD Monitor able to withstand the harsh environments commonly present with industrial display applications.  This Desktop Industrial Flat Panel Display is a rugged, high performance Active Matrix Color TFT LCD monitor, intended for demanding applications that require a high quality Industrial LCD Display.  These Metal Enclosure Industrial Grade LCD Monitors are designed from the ground up to be compatible, flexible and adaptable as CRT Replacement monitors for any Industrial Computer Display requirement. This Industrial Tabletop LCD Display accepts a variety of legacy signal formats including older RS-170 and RS-343 composite video sync-on-green (SOG) signal formats up to SXGA resolutions.  For other legacy or replacement applications, this 17 in Tabletop LCD display can be configured for compatibility with CGA/EGA/MDA and virtually any sub VGA signal, analog or digital. Options include: TTL Video Input; Single or Differential, Enhanced Sunlight Readable Glass, Anti-Reflected Tempered Glass, RGB Sync on Green (SOG) operation, various Touch Screen technologies and many others.  Our industrial LCD monitors are designed for industrial display applications such as manufacturing, financial, transportation and other severe environments requiring Rugged Tabletop Industrial Monitors with bright, crisp images. So, if you require a tough, versatile, high quality display, please contact out display experts to find out more.

QES1517 Table Top Series Series Features

  • 17” SXGA High Brite Color TFT LCD with Solid State LED Backlight Module
  • High Contrast – 1000:1 Typical
  • Bonded Anti-Reflective Protective Faceplate Glass for Superior Optical Performance and Better Protection
  • 15 to 100 KHz - Designed for Slow Scan Signals
  • 5 BNC - RGB Sync On Green, RGB Separate and RGB Composite Sync
  • VGA HD-15D-Sub
  • Standard VESA Input Timings
  • TTL CGA, EGA and MDA Input Signal - 9 Pin D-Sub
  • RCA (NTSC / PAL) and 5 Pin Mini Din (S-video)
  • Picture-In-Picture (PIP)
  • Picture-Outside-Picture (POP)
  • Front Controls
  • Heavy Duty Aluminum Front Bezel
  • Heavy Duty Cold Roll Steel Chassis
  • Internal Ruggedized Construction
  • VESA 100 Standard Mounting
  • Universal Power Supply with VESA Power Management

Other Options Include

  • Conformal Coating of Internal Circuit Boards for Enhanced Ruggedization
  • High Brightness TFT LCD Option – 1,500 Nits
  • Manual Dimming Control
  • Aspect Ratio: 1:1 or 4:3 (OSD Selection)
  • Differential Video Input for Enhanced Noise Immunity
  • RS170 - RS343 Video Input
  • Touch Screen: Resistive, Capacitive and SAW
  • Wireless Remote Control.
