Dynamic Displays QES2014-212,
14 In RGB CRT Monitor Replacement

Model QES1512-205 12.1 In LCD replaces Dynamic Displays, Inc. QES2014-212, 14 In Color CRT Monitor used in Mazak / Mitsubishi Control System.

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.


Dynamic Displays, Inc. QES2014-212 14" Color CRT Monitors used in Mazak Systems

Check out Dynamic Displays New Model QES1512-212 LCD display the next time you need a Replacement Monitor for your Mazak 14 Inch Mitsubishi M32 Control or Mazak Mitsubishi T32 Controls.  Our QES1512-205 LCD display is a drop in replacement for your 14-inch Mazak CNC monitor.

The QES1512-205 is a premium-quality TFT LCD flat panel display that directly replaces the following 14-inch CRT Monitors:

 KME 26S-14019C
 KME 26S-14019L
 Sharp 8DSP40
 Sharp AIQA8DSP40
Mitsubishi Electric C-5470
Mitsubishi Electric C-5470NS
Hitachi CD1472D1M-2
Mitsubishi Electric D0506-22
Mitsubishi Electric D0506-23
 Mazak  D72MA001840
 Data Ray Model DR5614 - P/N-800291
 Omni Vision E14DC-ZL-REV.1
 Omni Vision FP12B4G1-ZL
 Omni Vision FP12B4G0-ZL

Its rugged steel chassis is designed to drop right into the existing mounting brackets. In addition, the QES1512-205 LCD Display can also replace your Mazatrol monitors, Meldas Monitors, Sharp CNC monitors, Yamazaki monitors and many others.

Upgrading your old console unit with a QES1512-205 Mazak 14 Inch Replacement Monitor is a cost-effective way of extending the useful life of your existing automation investment.  What’s more, our QES1512-205 12.1 Inch LCD Monitor also functions with modern, VESA-standard signals, making system upgrades even easier.  Replace your old, low-performance CRT display unit with a new, affordable, high-quality replacement LCD Flat Panel display from Dynamic Displays, Inc.

QES1512-205 Series Features

  • Direct replacement for 8DSP40 Mazak Monitor
  • Direct replacement for C-5470 Mazak Monitor
  • Direct replacement for 26S-14O19L Mazak Monitor
  • Direct replacement for CD1472-D1M Mazak Monitor
  • Open-Frame Chassis drops directly into a Mazak Mitsubishi M32 and T32 Control Console
  • Mazak Special Timing - Standard TTL Input
  • Input Signal Connector: 15 Pin Molex Connector
  • 12.1” TFT-LCD Display with LED Backlight Module
  • Power Requirements: 100-240VAC 50-60Hz @ 1Amp

Other Options Include

  • Anti-Reflective Protective Faceplate
  • Strengthened Glass Protection
  • Wireless Remote Control
